MerCruiser

COMPLETE WATER PUMP KITS - DRIVE MOUNTED

No. 12098 No. 12120
OEM: 817275A5 OEM: N/A

Kit Contains:
Kit Contains: GLM OEM ITEM GLM OEM ITEM
GLM OEM ITEM GLM OEM ITEM 12323 46-57234A1 Pump Base 31050 27-42631-1 Gasket
11071 28-43037 Key 81390 25-896523 O-ring 12410 46-96148T1 Pump Housing 31170 (2) 26-8M0058390 Gasket
12341 807929A1 Pump Base 82115 (2) 25-21836 O-ring 12510 32435-1 Wear Plate 81160 25-30613 O-ring
12413 N/A (N.S.S.) Pump Hsg. 82150 25-35027 O-ring 12820 23-29804T Guide Tube 82260 25-33145 O-ring
12500 817276-1 Wear Plate 85140 26-45577-1 Seal 21330 25-30271 Slinger 82270 25-38099 O-ring
30090 27-43033-1 Gasket 89630 47-043026T2 Impeller 31010 27-85608-1 Gasket 85150 26-45577-1 Seal
31170(2) 26-8M0058390 Gasket 85592 26-861415A1 Face Seal 31020 27-858524 Gasket 89840 47-89984T4 Impeller
31240 27-817277-1 Gasket w/ Tool 31040 27-856704 Gasket
Alpha One Gen II MR / Alpha One (1984-1990)
No. 12110 No. 12130 Comes with Flush Screw
OEM: N/A OEM: N/A

Kit Contains: Kit Contains:
GLM OEM ITEM GLM OEM ITEM GLM OEM ITEM GLM OEM ITEM
12310 46-57234A1 Pump Base 31020 27-858524 Gasket 12330 46-48748A1 Pump Base 31020 27-858524 Gasket
12410 46-96148T1 Pump Housing 31040 27-856704 Gasket 12410 46-96148T1 Pump Housing 31040 27-856704 Gasket
12510 32435-1 Wear Plate 31170 (2) 26-8M0058390 Gasket 12510 32435-1 Wear Plate 31170 (2) 26-8M0058390 Gasket
12820 23-29804T Guide Tube 81160 25-30613 O-ring 12820 23-29804T Guide Tube 81160 25-30613 O-ring
21330 25-30271 Slinger 85140 26-45577-1 Seal 21330 25-30271 Slinger 85150 26-45577-1 Seal
31010 27-85608-1 Gasket 89840 47-89984T4 Impeller 31010 27-85608-1 Gasket 89840 47-89984T4 Impeller
MC-1 / R (1970-1983) MC-1 (1969 & Below)

WATER PUMP UPPER HOUSING KIT - DRIVE MOUNTED

No. 12280
OEM: 46-96148T8
Kit Contains:
GLM OEM ITEM GLM OEM ITEM
12410 48-96148A1 Housing 81390 25-90011 O-ring
12510 32435 Wear Plate 82250 25-30224 O-ring
12820 23-29804 Guide Tube 82260 25-33145 O-ring
21330 25-30271 Slinger 85140 26-45577-1 Seal
31010 27-85608-1 Gasket 89840 47-89984T4 Impeller
31020 27-858524 Gasket
31030 27-32438 Gasket
31040 27-856704 Gasket
31050 27-42631-1 Gasket
31170 (2) 26-8M0058390 Gasket
81160 25-30613 O-ring

MC-1 / R / MR / Alpha One

www.glmmarine.com
121
