MerCruiser

WATER PUMP IMPELLER REPAIR KITS - DRIVE MOUNTED

No. 12080 No. 12043
OEM: N/A OEM: 47-8M0094529

Kit Contains: Kit Contains:
GLM OEM ITEM GLM OEM ITEM GLM OEM ITEM
12341 807929A1 Carrier Assembly 11071 28-43037 Key 31170 26-8M0058390 Gasket (2)
12500 817276-1 Wear plate 12500 817276-1 Wear plate 31240 27-817277-1 Gasket
30091 27-43033-1 Gasket 82115 25-21836 O-ring (2) 85140 26-45577-1 Seal
31240 27-817277-1 Gasket 82130 25-90196 O-ring 85592 26-861415A1 Face Seal
89630 47-43026T2 Impeller 30091 27-43033-1 Gasket w/ Tool
89630 47-43026T2 Impeller
Alpha One Gen II Alpha One Gen II
No. 12290 No. 39530
OEM: 47-89984T5 OEM: N/A

Kit Contains:
GLM OEM ITEM GLM OEM ITEM
12510 32435-1 Wear Plate 31170 (2) 26-8M0058390 Gasket Kit Contains:
12820 23-29804T Guide Tube 81390 25-90011 O-ring GLM OEM ITEM GLM OEM ITEM
12830 26-38970 Grommet 81160 25-30613 O-ring 21330 25-30271 Slinger 81390 25-90011 O-ring
21330 25-30271 Slinger 82250 25-30224 O-ring 31010 27-85608-1 Gasket 81160 25-30613 O-ring
31010 27-85608-1 Gasket 82260 25-33145 O-ring 31020 27-858524 Gasket 82240 25-26722 O-ring
31020 27-858524 Gasket 82270 25-38099 O-ring 31030 27-32438 Gasket 82250 25-30224 O-ring
31030 27-32438 Gasket 85140 26-45577-1 Seal 31040 27-856704 Gasket 82260 25-33145 O-ring
31040 27-856704 Gasket 89840 47-89984T4 Impeller 31050 27-42631-1 Gasket 82270 25-38099 O-ring
31050 27-42631-1 Gasket 31170 (2) 26-8M0058390 Gasket 85140 26-45577-1 Seal
MC-1 / R / MR / Alpha One MC-1 / R / MR / Alpha One

WATER PUMP & SEALS SERVICE KITS
No. 88010 No. 88020
OEM: N/A OEM: N/A

Kit Contains: Kit Contains:
GLM OEM ITEM GLM OEM ITEM
12110 46-57234A3 Complete Water Pump Kit 12120 46-44292A5 Complete Water Pump Kit
87500 26-32511A1 Upper Housing Seal Kit 87500 26-32511A1 Upper Housing Seal Kit
87510 26-33144A2 Lower Housing Seal Kit 87510 26-33144A2 Lower Housing Seal Kit
MC-1 / R (1970-1983), S/N # 2663442-6225576 MR / Alpha One (1984-1990), S/N # 6225577 & Up

122
