Cobra



                                   LOWER GEAR HOUSING GEARS


         HEAVY DUTY




         Gear Set GLM #22666

         Includes #21651 thrust washer**


          When all three gears need replacing in your OMC Cobra Sterndrive the installation of the GLM
          #22666 heavy-duty gear set is highly recommended.   The heavy-duty gears can be used with
          all four-cylinder sterndrives* from 1990-1993 and all V6 and V8 OMC Cobra sterndrives from
          1986-1993. It is recommended that a new clutch GLM #22625 (this clutch is not included with
          the gear set) be installed with the heavy-duty gears.  The gears can be used with the standard
          1-3/16" diameter prop shaft (1986-1990) or the heavy-duty 1-1/4” diameter prop shaft (1991-
          1993).



             GLM #22666 heavy-duty gears fit these                     STRONGER
             OMC Cobra Sterndrive units:                         OEM gear sets are machined from
                                                                 8620 forged steel. The GLM gear set is
                                                                 machined from a higher alloy forged
             3.0L/181CI    4-Cyl. Chev.          1990-93         steel. The stronger teeth and higher
             4.3L/262CI    V6      Chev.         1986-93         alloy steel results in a gear that is 50%
                                                                 stronger than any other comparable
             5.0L/302CI    V8      Ford          1986-93         gear set. These durable gears are
             5.0L/305CI    V8      Chev.         1986-93         capable of operating with up to 300
                                                                 horsepower.
             5.7L/350CI    V8      Chev.         1986-93
             5.8L/351CI    V8      Ford          1986-93               MORE DURABLE
                                                                 The new GLM gear set has fewer,
                                                                 larger, and stronger teeth. The pinion
                                                                 gear has 12 teeth and the forward and
                                                                 reverse gears have 22 teeth. The
             IMPORTANT NOTE:                                     original OEM gear set has 14 teeth on
                                                                 the pinion and 26 teeth on the forward
                                                                 and reverse gears.
            The new heavy-duty GLM #22666 gears
            will not interchange with the standard                     QUIETER
            Cobra gears.  For individual Cobra gear              During the gear machining process,
            replacement, you must use the standard               an additional pass is made over each
                                                                 tooth for a finer surface. This makes
            duty GLM #22623 pinion and forward                   the gear operation especially quiet.
            gears or the GLM #22624 reverse gear.



          *Except 1990 2.3L
          **For model year 1991 OMC increased the prop shaft diameter at the carrier needle bearing (not the prop splines) from 1-3/16 to 1-1/4 inches.
          Some older gearcases may be fitted with the new large diameter prop shaft.  The large diameter prop shaft utilizes a thrust washer (included
          with this gear set) between the prop shaft and reverse gear.  Discard the thrust washer when using the small diameter prop shaft.


      42
