Johnson / Evinrude



                       LOWER GEAR HOUSING GEARS - V6 90° “O” TYPE



                                          V6 90°


                                          Replacement Gears for the

                                          “O” Type Gear Housing




                    These gear sets are an exact copy of the gears used in the 1978-2006
                    V6 Johnson / Evinrude Outboards with the large “O” type gear housing.


                                                  1.86:1 Ratio
                                                    .54 Ratio













                              No. 22623                      No. 22624      No. 21651   No. 22625
                          Forward & Pinion Set             Reverse Gear    Thrust Washer  Clutch Dog



                 COMPLETE GEAR SET
                 - Forward/Pinion/Reverse            GLM No. 22622            OEM No. 5004218
                 - 14/26 teeth
                 - Comes with the GLM No. 22625 clutch


                 FORWARD & PINION SET                                         OEM No. 0435020
                 - May be used with OMC reverse gear  GLM No. 22623           OEM No. 5004216
                 - 14/26 teeth                                                OEM No. 5004938

                 REVERSE GEAR
                 - May be used with OMC forward and                           OEM No. 0336561
                   pinion gears                      GLM No. 22624
                 - 26 teeth                                                   OEM No. 0910994
                 - Includes thrust washer No. 21651*



                 CLUTCH                              GLM No. 22625            OEM No. 0337774




                * For model year 1991 Johnson / Evinrude increased the prop shaft diameter at the carrier needle bearing (not the prop splines) from
                1-3/16” to 1-1/4”. Some older gearcases may be fitted with the new large diameter prop shaft. The large diameter prop shaft utilizes a
                thrust washer (included with this gear set) between the prop shaft and reverse gear. Discard the thrust washer when using the small
                diameter prop shaft.


      56
