MerCruiser
DISTRIBUTOR ASSY COMPONENTS APPLICATION ELECTRONIC IGNITIONS
Model # Cyl. Ignition Year(s) Serial No. Range Distributor Assy.
7.4LX Bravo MPI 454 / V8 Delco 1996 0F820000-0K147349 -
7.4LX Bravo MPI 454 / V8 Delco 1997 0K147350-0K999999 -
7.4L MPI (L29) 454 / V8 Delco 1998 0L010003-0L085005 -
7.4L MPI (L29) 454 / V8 Delco 1998-2001 0L085006 & Up -
340/7.4L MIE 454 / V8 Thunderbolt IV 1981-1992 5889914-0D715493 71250
7.4L MIE 454 / V8 Thunderbolt IV (2) 1992-1996 0D715494-0F820141 71250
7.4L MIE 454 / V8 Thunderbolt IV (1) 1992-1996 0D715494-0F820141 71250
7.4L MIE 454 / V8 Thunderbolt V 1992-1996 0D715494-0K999999 71250
7.4L TBI MIE 454 / V8 Delco 1996-1997 0F874815-0K999999 -
7.4L MPI MIE 454 / V8 Delco 1995-1996 0F563052-0F820103 -
7.4L MPI MIE 454 / V8 Delco 1996 0F820104-0K146534 -
7.4L MPI MIE 454 / V8 Delco 1997 0K146535-0K999999 -
7.4L MPI MIE (L29) 454 / V8 Delco 1998 0L002006-0L086006 -
7.4L MPI MIE (L29) 454 / V8 Delco 1998-2001 0L086007 & Up -
370 TRS 454 / V8 Thunderbolt IV 1985-1987 6721528-0B714586 71250
420 454 / V8 Thunderbolt IV 1987-1989 0A398941-0B622418 71250
450 454 / V8 Thunderbolt IV 1995-1996 0F347100-0F347277 71250
454 Mag. Alpha 454 / V8 Thunderbolt IV 1986-1988 0A631894-0B785148 71250
454 Mag. Bravo 454 / V8 Thunderbolt IV (2) 1988-1992 0B721206-0D805068 71250
454 Mag. Bravo 454 / V8 Thunderbolt IV (1) 1988-1992 0B721206-0D805068 71250
454 Mag. Bravo 454 / V8 Thunderbolt IV 1992-1994 0D805069-0F304999 71250
454 Mag. Bravo 454 / V8 Thunderbolt V 1992-1997 0D805069-0K999999 71250
454 EFI 454 / V8 Delco 1994-1996 0F115700-0F802349 -
454 EFI 454 / V8 Delco 1994-1996 0F115700-0F802349 -
454 Mag. MPI 454 / V8 Delco 1996 0F802350-0K147349 -
454 Mag. Ski 454 / V8 Delco 1997-1998 0K147350-0L085009 -
454 Mag. Ski 454 / V8 Delco 1998-2001 0L085010 & Up -
454 Mag. MPI Horizon MIE 454 / V8 Delco 1998-2001 0L002200-0L086000 -
454 Mag. MPI Horizon MIE 454 / V8 Delco 1998-2001 0L086001 & Up -
454 Mag. MPI Ski 454 / V8 Delco 1995-1996 0F215800-0F820099 -
454 Mag. MPI Ski 454 / V8 Delco 1996-1997 0F820100-0K999999 -
500 502 / V8 Thunderbolt IV 1994-1996 0F213293-0F745159 71250
500 502 / V8 Thunderbolt IV 1997-1998 0F745195-0L001772 71250
500 (Gen+) 502 / V8 Thunderbolt IV 1999-2000 0L414639 & Up 71250
500 EFI 502 / V8 Delco 1998-2000 0L001477 & Up -
502 Mag. 502 / V8 Thunderbolt IV (2) 1990-1993 0C878221-0F114528 71250
502 Mag. 502 / V8 Thunderbolt IV (1) 1990-1993 0C878221-0F114528 71250
502 EFI 502 / V8 Delco 1993-1996 0D840650-0F802599 -
502 Mag. MPI 502 / V8 Delco 1996 0F802600-0K147349 -
502 Mag. MPI 502 / V8 Delco 1997-1998 0K147350-0L085000 -
502 Mag. MPI 502 / V8 Delco 1998 0L085001 & Up -
8.2L MIE 502 / V8 Thunderbolt IV 1990-1992 0C878221-0D857199 71250
8.2L MIE 502 / V8 Thunderbolt IV (1) 1993-1996 0D857200-0F819619 71250
8.2L MIE 502 / V8 Thunderbolt V 1993-1996 0D857200-0F819619 71250
8.2L MPI MIE 502 / V8 Delco 1996 0F819620-0K145121 -
8.2L MPI MIE 502 / V8 Delco 1997-1998 0K145122-0L086012 -
8.2L MPI MIE 502 / V8 Delco 1998 0L086013 & Up -
525 SC 502 / V8 Thunderbolt IV 1991-1995 0D456000-0F877734 71250
525 SC 502 / V8 Thunderbolt IV 1996-1997 0K000012 & Up 71250
575 Sci 502 / V8 Delco 200-2001 0L306696 & Up -
600 SC 502 / V8 Thunderbolt IV 1991-1993 0D456489-0D763875 71250
600 SC 502 / V8 Thunderbolt IV 1993-1996 0D763876-0F877642 71250
600 SC 502 / V8 Thunderbolt IV 1997-2001 0K000227 & Up 71250
500 Bulldog 540 / V8 Thunderbolt IV 1990-1996 0C577003-0F745405 71250
500 Bulldog 540 / V8 Thunderbolt IV 1997-1998 0K000248-0L001607 71250
500 Bulldog 540 / V8 Thunderbolt IV 1999-2000 0L414620 & Up 71250
575 540 / V8 Thunderbolt IV 1986-1992 0A677429-0D763716 71250
800 SC 572 / V8 Thunderbolt IV 1993-1996 0D763836-0F877725 71250
800 SC 572 / V8 Thunderbolt IV 1997-2001 0K000223 & Up 71250
