MerCruiser

IGNITION COILS ALTERNATOR BRACKET

No. 72110 No. 72115 No. 74009
IGNITION COIL IGNITION COIL ALTERNATOR BRACKET
OEM: 392-806529A1 OEM: 392-805570A2 OEM: 93175T

Now Sold
Separately!

Used with Points Style Ignition Used withThunderbolt IV
and Resistor Wire and Thunderbolt V * For use with No. 58990 Manifold Conversion Kits
Use w/ External Resistor Use w/out External Resistor GM 305 & 350 CID

IMPORTANT INFORMATION

Mercruiser installs various makes of ignition distributors into the engines it sells.
These are: Delco Marine, Prestolite, Mallory, and Mercruiser Thunderbolt.
It is the customers' responsibility to know what distributor is in the boat being serviced.

Note:
All 4 & 6-Cyl. Inline Engines use Delco Distributors.
All V6 Engines with Breaker Points use Prestolite Distributors.

GLM TO OEM (POINTS, CONDENSERS, ROTORS & CAPS)

Points Condensers
Description GLM No. OEM No. Description GLM No. OEM No.
Prestolite 1-42V 70010 392-6325 Prestolite 2-96 70510 392-6324
Delco 4 & 6 D108 70020 34235 Delco 4 & 6 D 204 - 33662
Delco V8 70030 33700 Delco V8 70580 391-898253001
Mallory 25042 - 391-5090 Mallory 70580 391-5092
Prestolite 70040 898253007 Prestolite 70540 81-64851
Rotors Caps

Description GLM No. OEM No. Description GLM No. OEM No.
Delco 4 & 6 D423 71020 58217 MerCruiser V6 71500 13753A2
Delco V8 71010 33707 MerCruiser V8 71510 16457A4
Mallory 309 - 391-7057 Delco 6 71530 33765
Prestolite4-101 71060 392-0080 Delco 4 71540 393-9459
MerCruiser V6 72890 13524A6 Delco V8 71520 33708
MerCruiser V8 72880 13524T1 Prestolite V8 3-142 - 293-6318
Prestolite 71030 65864 Mallory V8 - 391-5075T1
Prestolite V6 3-149 71600 392-9086
Prestolite 71550 393-4988T2

www.glmmarine.com
153
