Mercury / Mariner / Force

PROP SHAFT COMPONENTS - L4, L6 & V6 (65-225 HP)

Late Alpha Gearcase (4.75in/120.6mm Torpedo Dia.)
No. 11410 No. 21620 No. 11430 No. 11420 No. 21820 No. 21830 No. 23220
PROP SHAFT REVERSE GEAR See Section FORWARD GEAR FORWARD GEAR FORWARD GEAR FORWARD GEAR SHIM SET
BEARING BEARING 3 for Gears INSIDE BEARING INSIDE BEARING OUTSIDE BEARING OUTSIDE BEARING OEM: 15-47397A1
OEM: 31-30956 OEM: 30-88957T OEM: 31-54928-1 OEM: 31-30895T OEM: 31-30894A1 OEM: 31-78172A1

No. 85700 No. 85130 No. 83445
PROP SHAFT PROP SHAFT O-RING FOR
OUTER SEAL INNER SEAL BEARING CARRIER
OEM: 26-12224 OEM: 26-76868 OEM: 25-896524

No. 11155 No. 11152
PROP SHAFT PROP SHAFT
OEM: 44-850308 OEM: 44-93003
No. 11151
PROP SHAFT
OEM: 44-94148
PROP SHAFT COMPONENTS - V6 3.0L (200 DFI, 225 CARB, 225 & 250 EFI)

Late 3.0L Alpha Gen II Gearcase

No. 11410 No. 21620 No. 23140 No. 11420 No. 21590 No. 21593 No. 21820 No. 23220
PROP SHAFT REVERSE GEAR THRUST RING FORWARD GEAR FORWARD GEAR FORWARD GEAR FORWARD GEAR SHIM SET
BEARING BEARING OEM: 68100-1 INSIDE BEARING OUTSIDE BEARING OUTSIDE BEARING OUTSIDE BEARING OEM: 15-47397A1
OEM: 31-30956 OEM: 30-88957T OEM: 31-30895T OEM: 31-35928A1 OEM: 31-828439A2 OEM: 31-30894A1 (For 21590 Bearing)
(For 1.65:1 Ratio) (For 1.62:1 Ratio) (For 1.75:1 Ratio)
No. 23221
SHIM SET
OEM: 15-44491A1
(For 21593, 21820
Bearings)

No. 85700 No. 85130 No. 11405 No. 83445
PROP SHAFT PROP SHAFT BEARING CARRIER O-RING FOR
OUTER SEAL INNER SEAL W/ BEARINGS & SEALS BEARING CARRIER
OEM: 26-12224 OEM: 26-76868 OEM: 818763A11 OEM: 25-896524

No. 11155
PROP SHAFT
OEM: 44-850308
