Water/Fuel Separator Kits

NEW! Racor Style Water / Fuel Separators w/ Collection Bowls

Inline Fuel Filter Diagram

No. 25230
Stainless Steel Bracket
w/ Clear Collection Bowl

10 Micron
1/4" NPTF Ports
Flow: 60 GPH

For Outboard use only
ABOVE deck installations


No. 25240
Stainless Steel Bracket
w/ Clear Collection Bowl

10 Micron
3/8" NPTF Ports
Flow: 60 GPH

For Outboard use only
ABOVE deck installations



No. 25210
Aluminum Bracket
w/ Clear Collection Bowl

10 Micron
1/4" NPTF Ports
Flow: 60 GPH

For Outboard use only
ABOVE deck installations


No. 25220
Aluminum Bracket
w/ Clear Collection Bowl

10 Micron
3/8" NPTF Ports
Flow: 60 GPH

For Outboard use only
ABOVE deck installations



No. 25250
Fuel Filter Element
w/ Clear Collection Bowl

10 Micron
11/16-16 Center Threads
Flow: 60 GPH

For Outboard use only
ABOVE deck installations


No. 25200
Fuel Filter Element with
Viton O-ring No. 82367

10 Micron
11/16-16 Center Threads
Flow: 60 GPH

For Outboard use only
ABOVE deck installations



No. 25005
Clear Collection Bowl w/
Viton O-ring No. 82367

E10 Ethanol Compatible
Spin-On to Filter Element
For Marine Use

For Outboard use only
ABOVE deck installations


GLM's Water / Fuel Separator Kits with Low Pick-Up Mounting Bracket

Eliminate Fuel Starvation with GLM's Low Pick-Up Water/Fuel Separator Mounting Bracket!

Engine compartment temperatures can soar on hot summer days creating high gasoline temp-
eratures. High temperatures and agitation caused by rough seas can aerate the gasoline in the
water/fuel separator filter turning it into foam. A fuel pump can’t pull aerated gasoline from the
water/fuel separator and deliver it to the carburetor or fuel rail efficiently. The engine will show
signs of gasoline starvation (lean) at high speeds, a situation very similar to vapor lock.

Because this aerated gasoline rises to the top of the water/fuel separating filter, GLM has intro-
duced a filter mounting bracket with a fuel pickup extending deeper into the filter. Through exten-
sive research and testing, GLM engineers have found the optimum location for the fuel pickup.
The deeper location is low enough to be free of aerated gasoline but high enough to be free of
the water in the bottom of the separator.

CONVENTIONAL DESIGN

Air molecules rise to top
and into the fuel system.
GLM DESIGN

Our design prevents air from
entering the fuel system.

The deeper fuel pickup is found only on the new GLM water/fuel separator mounting bracket kits.
It might solve some of those mysterious fuel delivery problems your engine may be experiencing!

For trouble free boating always remember to replace your water/fuel separating filter
after every 50 hours of engine operation!


No. 24956
Stainless Steel Bracket
28 Micron
1/4" NPTF Ports
Flow: 50 GPH

No. 24958
Stainless Steel Bracket
28 Micron
3/8" NPTF Ports
Flow: 75 GPH

No. 24957
Stainless Steel Bracket
10 Micron
1/4" NPTF Ports
Flow: 50 GPH

No. 24959
Stainless Steel Bracket
10 Micron
3/8" NPTF Ports
Flow: 75 GPH



No. 24960
Red Stainless Steel Bracket
28 Micron
1/4" NPTF Ports
Flow: 50 GPH

No. 24962
Red Stainless Steel Bracket
28 Micron
3/8" NPTF Ports
Flow: 75 GPH



No. 24950
Die Cast Aluminum Bracket
28 Micron
1/4" NPTF Ports
Flow: 50 GPH

No. 24953
Die Cast Aluminum Bracket
28 Micron
3/8" NPTF Ports
Flow: 75 GPH

No. 24952
Die Cast Aluminum Bracket
10 Micron
1/4" NPTF Ports
Flow: 50 GPH

No. 24954
Die Cast Aluminum Bracket
10 Micron
3/8" NPTF Ports
Flow: 75 GPH


Click to Download NEW! Racor Style Water/Fuel Separator Kits w/ Collection Bowl Flyer.
Click to Download Water/Fuel Separator Kits w/ Low Pick-Up Bracket Flyer.
