Johnson / Evinrude

DRIVE SHAFT COMPONENTS - V4 & V6

V4 60° & V4 90° V4 & V6 “O” & “M” Type

Small Gearcase Large Gearcase
V4 60° (1995-2006) “O” Type (1978-2006)
V4 90° (1978-1998) “M” Type (2002-2006)

No. 86011 No. 22405 No. 86011 No. 22407
OIL SEAL LOWER D.S.-V4 60° OIL SEAL LOWER D.S.
OEM: 0341280 OEM: 0346004 OEM: 0341280 “O” TYPE
OEM: 0345905
No. 22362 No. 22362
SCREW SCREW
OEM: 0317624 OEM: 0317624

No. 22720 No. 22409 No. 22720 No. 22403
BEARING HSG. LOWER D.S. - V4 90° BEARING HSG. LOWER D.S.
& SEAL OEM: 0346006 & SEAL “M” TYPE
OEM: 0439476 OEM: 0439476 OEM: 0347371

No. 81380 No. 81380
O-RING, LOWER O-RING, LOWER
OEM: 0314728 OEM: 0314728

No. 23590 No. 22880 No. 23590 No. 21610
SHIM 0.003” PINION BEARING SHIM 0.003” PINION BEARING
OEM: 0323362 OEM: 0384195 OEM: 0323362 OEM: 0387817

No. 23580 No. 23580 See Section 4
SHIM 0.004” See Section 4 SHIM 0.004” for Gear Sets
for Gear Sets
OEM: 0323361 OEM: 0323361
No. 32800
No. 23510 No. 23510 WASHER
SHIM 0.005” SHIM 0.005” “M” TYPE
OEM: 0314745 OEM: 0314745 OEM: 0350038

No. 21645 No. 11190 No. 21645 No. 11190
THRUST WASHER PINION NUT THRUST WASHER PINION NUT
OEM: 0327656 OEM: 0314730 OEM: 0327656 OEM: 0314730

No. 16330 No. 16330
THRUST BEARING THRUST BEARING
OEM: 0387656 OEM: 0387656

No. 28351 No. 28351
RETAINER RETAINER
OEM: 0338504 OEM: 0338504

No. 21139 No. 21139
PIN PIN
OEM: 0311538 OEM: 0311538
