Johnson / Evinrude
3-CYLINDER LOOPCHARGED PISTONS
Loopcharged Pistons for 3-Cylinder 60 HP, 65 HP, 70 HP (1994-2001)
Johnson / Evinrude Outboards
These engines use ø 3.1875” pistons with
traditional (rectangular) rings
60 HP 1994-2001
65 HP 1994-2001
70 HP 1994-2001
Pistons for above engines
GLM Piston No. Size OEM Piston No.
23740 ø 3.1875 5006694
23750 ø 3.1875 +.020 5006707
23760 ø 3.1875 +.030 5006695
all pistons come with rings, pin and retainers
Rings for above ø 3.1875” pistons
Rings are 2 mm thick
GLM Ring No. Size OEM Ring No.
24540 ø 3.1875 0436972
24550 ø 3.1875 +.020 N/A
24560 ø 3.1875 +.030 0436973
all rings come 2 to a set
www.glmmarine.com 111
