Johnson / Evinrude
V4 90° / V6 90° / V8 LOOPCHARGED PISTONS
Loopcharged Pistons for 90 Degree V4/V6/V8
Johnson / Evinrude Outboards
These 1988 and newer engines use ø 3.6875” pistons
120 HP 90 Degree V4 1988-1994
140 HP 90 Degree V4 1988-1994
200 HP 90 Degree V6 1988-1992
225 HP 90 Degree V6 1988-1992
250 HP 90 Degree V8 1991-1998
300 HP 90 Degree V8 1988-1995
Pistons for above engines
GLM Piston No. Size OEM Piston No.
Port Starboard Port Starboard
24050 24100 ø 3.685 5006675, 5006671 5006676, 5006672
24070 24120 ø 3.685 +.020 N/A N/A
24090 24140 ø 3.685 +.030 5006673, 5006677 5006674, 5006678
all pistons come with rings, pin and retainers
Rings for above ø 3.6875” pistons
GLM Ring No. Size OEM Ring No.
24250 ø 3.685 0431870
24270 ø 3.685 +.020 N/A
24290 ø 3.685 +.030 0431844
all rings come 2 to a set
